Smart Senser™ is an automated measuring, monitoring and sensing device for every type of pipe, wire or sensor.
If there’s a conduit or a senser, a pipe or a wire, our unit can measure or monitor it.
SmartSenser™ – Intelligent Heating System Pressure Management
In this application the SmartSenser™ is used as an automated pressure monitoring and refilling device for wet heating systems. It intelligently maintains optimal pressure, alerts users to anomalies, and prevents damage by isolating the water supply when needed. Designed for both residential and commercial applications, it reduces maintenance calls, mitigates risk, and improves system performance.
Key Features
- Automatic Repressurisation
Monitors system pressure and refills as needed to maintain safe levels. - Remote Monitoring & Alerts
Sends real-time alerts via email or SMS when:- Pressure drops or exceeds thresholds
- A leak or abnormal water use is detected
- Repressurisation occurs frequently
- Leak & Usage Detection
Tracks water consumption patterns to identify leaks, stuck valves, or excessive use. - Safety Shutoff Valve
Automatically closes water feed if unsafe or continuous filling is detected. - Smart Analytics
Logs system behaviour for predictive maintenance insights.
Parameter |
|
Power Supply |
|
Connectivity |
|
Communication Protocols |
|
Pressure Range |
|
Fill Rate |
|
Isolation Valve |
|
Operating Temp Range |
|
Ingress Protection |
|
Data Logging |
|
Compliance |
|
Installation Time |
Value |
|
230V AC or 24V DC (configurable) |
|
Wi-Fi / GSM / LoRaWAN (model dependent) |
|
MQTT, HTTPS, SMS, Email |
|
0 – 4 bar |
|
Up to 5 L/min |
|
Electrically actuated |
|
0–80°C |
|
IP44 (standard), IP65 (optional) |
|
User defined, 12 months or longer (cloud synced) |
|
CE / UKCA (pending certification) |
|
~30 minutes by qualified engineer |
Ideal For
- Homes with pre-payment meters (where boiler lockouts are common)
- Landlords & housing associations (reduces callouts and service delays)
- Care homes, schools, and offices needing dependable, low-intervention heating systems
- Any site using sealed wet heating systems vulnerable to pressure loss
Installation & Support
SmartSenser is installed by certified engineers and includes:
- Secure cloud access to data and alerts
- Ongoing remote monitoring
- Full support and maintenance as part of service contract
